The USB3803C-1-GL-TR is a USB 2.0 3-port transceiver from Microchip, operating at a supply voltage of 3.3V. It features a data rate of 480Mbps and is packaged in a WLCSP-25. The device is RoHS compliant and has ESD protection. It is designed for surface mount applications and has a maximum operating temperature of 70°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip USB3803C-1-GL-TR datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Data Rate | 480Mbps |
| ESD Protection | Yes |
| Height | 0.38mm |
| Interface | USB |
| Lead Free | Lead Free |
| Length | 2mm |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 1.2V |
| Mount | Surface Mount |
| Number of Ports | 3 |
| Number of Transceivers | 3 |
| Operating Supply Voltage | 3.3V |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| USB Standard | USB 2.0 |
| Width | 2mm |
| RoHS | Compliant |
Download the complete datasheet for Microchip USB3803C-1-GL-TR to view detailed technical specifications.
