Frequency133MHz
PackageVFBGA
Current50mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Micron MT48H4M16LFB4-75:H technical specifications.
General
Access Time
6ns
Address Bus Width
14b
Package/Case
VFBGA
Data Bus Width
16b
Density
64Mb
Frequency
133MHz
Lead Free
Lead Free
Max Frequency
133MHz
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Supply Voltage
1.9V
Memory Size
64Mb
Memory Type
Volatile,
Min Supply Voltage
1.7V
Mount
Surface Mount
Operating Supply Voltage
1.8V
Organization
4MX16
Packaging
Tray
Radiation Hardening
No
RoHS Compliant
Yes
Supply Current
50mA
Compliance
RoHS
Compliant
Datasheet
Micron MT48H4M16LFB4-75:H Datasheet
Download the complete datasheet for Micron MT48H4M16LFB4-75:H to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
