The MP2451DT-LF-P is a 36V 600mA adjustable DC/DC controller in a SOT-23-6 package, suitable for surface mount applications. It operates over a temperature range of -40°C to 125°C and is lead free. The device has a maximum efficiency of 90% and a maximum output voltage of 28.8V. It is designed for use in DC/DC converter applications.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Monolithic Power Systems MP2451DT-LF-P datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOT-23-6 |
| Efficiency | 90% |
| Lead Free | Lead Free |
| Max Input Voltage | 36V |
| Min Input Voltage | 3.3V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 600mA |
| Max Output Voltage | 28.8V |
| Min Output Voltage | 800mV |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Operating Supply Voltage | 36V |
| Output Configuration | Positive |
| Output Current | 600mA |
| Output Type | Adjustable |
| Output Voltage | 800mV |
| Packaging | Tape and Reel |
| Synchronous Rectifier | No |
| Weight | 0.00127oz |
| RoHS | Compliant |
