Technical Specifications
Monolithic Power Systems MP3391EY-LF-Z technical specifications.
General
Package/Case
SOIC
Dimming
PWM
Frequency
280kHz
Lead Free
Lead Free
Max Operating Temperature
85°C
Min Operating Temperature
-20°C
Max Power Dissipation
2.1W
Max Supply Voltage
35V
Mount
Surface Mount
Number of Outputs
8
Output Current per Channel
120mA
Package Quantity
1000
Packaging
Tape and Reel
Radiation Hardening
No
RoHS Compliant
Yes
Topology
Boost
Compliance
RoHS
Compliant
Datasheet
Monolithic Power Systems MP3391EY-LF-Z Datasheet
Download the complete datasheet for Monolithic Power Systems MP3391EY-LF-Z to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
