The P6KE33CA is a bidirectional transient voltage suppressor with a maximum breakdown voltage of 34.7V and a minimum breakdown voltage of 31.4V. It has a maximum power dissipation of 5W and a peak pulse power of 600W. The device is packaged in a DO-204AC case and is available on cut tape. The P6KE33CA is RoHS compliant but not SVHC compliant.
PackageDO-204AC
PolarityBidirectional
Power5W
Quick Jump:
Technical Specifications
Multicomp P6KE33CA technical specifications.
General
| Package/Case | DO-204AC |
| Max Breakdown Voltage | 34.7V |
| Min Breakdown Voltage | 31.4V |
| Max Power Dissipation | 5W |
| Packaging | Cut Tape |
| Peak Pulse Current | 13.8A |
| Peak Pulse Power | 600W |
| Polarity | Bidirectional |
| Power Dissipation | 5W |
| Reach SVHC Compliant | No |
| Reverse Standoff Voltage | 28.2V |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Multicomp P6KE33CA Datasheet
Download the complete datasheet for Multicomp P6KE33CA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
