Multi-layer ferrite bead, 120 Ohm impedance at 100MHz with 25% tolerance. Features a 300mA current rating and 550mOhm DC resistance. Housed in a compact 0402 (1005 metric) SMD/SMT package, this unshielded component operates from -55°C to 125°C and is supplied on tape and reel.
Frequency100MHz
Package0402
Current Rating300mA
Quick Jump:
Technical Specifications
Murata BLM15BB121SN1D technical specifications.
General
Case Code (Imperial)
0402
Case Code (Metric)
1005
Package/Case
0402
Core Material
Ferrite
Current Rating
300mA
DC Resistance (DCR)
550mR
DC Resistance-Max
550mR
Depth
0.5mm
Frequency
100MHz
Height
0.5mm
Impedance
120R
Lead Free
Lead Free
Length
1mm
Material
Ferrite, Steel
Max Current Rating
300mA
Max DC Current
300mA
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Number of Circuits
1
Number of Lines
1
Package Quantity
1
Packaging
Tape and Reel
Reach SVHC Compliant
No
RMS Current (Irms)
300mA
RoHS Compliant
Yes
Series
BLM15B
Series Resistance
550mR
Shielding
Unshielded
Termination
SMD/SMT
Test Frequency
100MHz
Tolerance
25%
Width
0.5mm
Compliance
RoHS
Compliant
Datasheet
Murata BLM15BB121SN1D Datasheet
Download the complete datasheet for Murata BLM15BB121SN1D to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
