Dual common mode choke for power and signal lines, featuring 90 Ohm impedance at 100MHz and a 330mA current rating. This surface mount component offers a low DC resistance of 350mR and operates within a temperature range of -40°C to 85°C. Packaged in an 0805 case, it is RoHS compliant and designed for efficient noise suppression.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Murata DLW21SN900SQ2L datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Murata DLW21SN900SQ2L technical specifications.
| Case Code (Imperial) | 0805 |
| Package/Case | 0805 |
| Current | 330mA |
| Current Rating | 330mA |
| DC Current | 330mA |
| DC Resistance (DCR) | 350mR |
| DC Resistance-Max | 410mR |
| Depth | 1.2mm |
| Height | 0.055inch |
| Impedance | 90R |
| Lead Free | Lead Free |
| Length | 2mm |
| Max DC Current | 330mA |
| Max Operating Temperature | 85°C |
| Military Standard | Not |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Lines | 2 |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | EMIFIL®, DLW21S |
| Series Resistance | 350mR |
| Shielding | Unshielded |
| Termination | SMD/SMT |
| Test Frequency | 100MHz |
| Tolerance | 25% |
| Voltage Rating | 50V |
| Weight | 0.000388oz |
| Width | 0.047inch |
| RoHS | Compliant |
