Digital panel voltmeter with LED display, measuring 8-50VDC. Features a 3.5 character display and operates with a 13mA input current. Designed for panel mounting with screw termination, this component has a BGA package and dimensions of 25.4mm x 35mm x 22mm. Operating temperature range is -25°C to 60°C.
PackageBGA
MountingPanel
Quick Jump:
Technical Specifications
Murata DMS-20PC-1-DCM-C technical specifications.
General
| Package/Case | BGA |
| Depth | 24.4mm |
| Display Type | Digital |
| Height | 22mm |
| Input Current | 13mA |
| Lead Free | Lead Free |
| Length | 25.4mm |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -25°C |
| Max Supply Voltage (DC) | 50V |
| Min Supply Voltage (DC) | 8V |
| Mount | Panel |
| Number Of Characters Per Row | 3.5 |
| Operating Supply Current | 13mA |
| Package Quantity | 12 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Series | DMS-20PC-0/1/2/8-DCM |
| Termination | Screw |
| Weight | 0.062lb |
| Width | 35mm |
Compliance
| RoHS | Compliant |
Datasheet
Murata DMS-20PC-1-DCM-C Datasheet
Download the complete datasheet for Murata DMS-20PC-1-DCM-C to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
