Murata
GRM0335C1H220GA01D
Capacitor, Ceramic, Chip, General Purpose, 22pF, 50V, ±2%, C0G/NP0, 0201 (0603 mm), 0.012"T, -55º ~ +125ºC, 7" Reel/Paper Tape
Package0201
Capacitance22pF
Voltage Rating50V
MountingSurface Mount
Quick Jump:
Technical Specifications
Murata GRM0335C1H220GA01D technical specifications.
General
Capacitance
22pF
Case Code (Imperial)
0201
Case Code (Metric)
0603
Package/Case
0201
Dielectric
C0G
Height
0.3mm
Lead Free
Lead Free
Length
0.024inch
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Mount
Surface Mount
Package Quantity
15000
Packaging
Tape and Reel
RoHS Compliant
Yes
Series
GRM
Termination
SMD/SMT
Thickness
0.013inch
Tolerance
2%
Voltage Rating
50V
DC Rated Voltage
50V
Width
0.012inch
Compliance
RoHS
Compliant
Datasheet
Murata GRM0335C1H220GA01D Datasheet
Download the complete datasheet for Murata GRM0335C1H220GA01D to view detailed technical specifications.
