The LXES15AAA1-117 is a single bidirectional Zener diode with a clamping voltage of 40V and a working voltage of 15V. It is designed for surface mount applications and has a package quantity of 10000 units per reel. The diode operates within a temperature range of -40°C to 85°C and is RoHS compliant. It is available in a 0402 package case code, suitable for compact designs. The LXES15AAA1-117 is a Murata product.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Murata LXES15AAA1-117 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Case Code (Imperial) | 0402 |
| Case Code (Metric) | 1005 |
| Package/Case | 0402 |
| Clamping Voltage | 40V |
| Diode Type | ZENER |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Operating Supply Voltage | 15V |
| Package Quantity | 10000 |
| Packaging | Tape and Reel |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Reverse Standoff Voltage | 15V |
| RoHS Compliant | Yes |
| Termination | SMD/SMT |
| Working Voltage | 15V |
| RoHS | Compliant |
