The Nexperia 74HC125PW-Q100J is a 14-pin TSSOP-14 logic IC with 4 functions, operating over a temperature range of -40°C to 125°C. It has a propagation delay of 150ns and is designed for automotive applications. The device is supplied with a nominal voltage of 5V, a maximum voltage of 6V, and a minimum voltage of 2V. It meets the AEC-Q100 screening level and is packaged in a 4.4mm x 5mm plastic package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Nexperia 74HC125PW-Q100J datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Nexperia 74HC125PW-Q100J technical specifications.
| Max Operating Temperature | 125 |
| Number of Terminals | 14 |
| Min Operating Temperature | -40 |
| Terminal Position | DUAL |
| JEDEC Package Code | R-PDSO-G14 |
| Width | 4.4 |
| Length | 5 |
| Pin Count | 14 |
| Number of Functions | 4 |
| Temperature Grade | AUTOMOTIVE |
| Supply Voltage-Nom (Vsup) | 5 |
| Supply Voltage-Max (Vsup) | 6 |
| Supply Voltage-Min (Vsup) | 2 |
| Logic IC Type | BUS DRIVER |
| Family | HC/UH |
| Propagation Delay (tpd) | 150 |
| Number of Bits | 1 |
| Output Polarity | TRUE |
| Number of Ports | 2 |
| Screening Level | AEC-Q100 |
| RoHS | Yes |
| REACH | Compliant |
| Military Spec | False |
