Aluminum electrolytic capacitor with 4700µF capacitance and 50V DC rating. Features 20% tolerance, 2.56A ripple current at 120Hz, and a maximum operating temperature of 105°C. This general-purpose capacitor has a 3000-hour life expectancy and a leakage current of 1.45mA. The radial package measures 22mm in diameter and 45mm in height, with a 10mm lead pitch and snap-in termination for through-hole mounting.
PackageRadial
Capacitance4.7mF
Voltage Rating50V
MountingThrough Hole
Quick Jump:
Technical Specifications
Nichicon LGU1H472MELZ technical specifications.
General
| Capacitance | 4.7mF |
| Package/Case | Radial |
| Diameter | 22mm |
| Dissipation Factor | 0.3% |
| Features | General Purpose |
| Height | 45mm |
| Height - Seated (Max) | 1.85inch |
| Lead Pitch | 10mm |
| Leakage Current | 1.45mA |
| Length | 40mm |
| Life (Hours) | 3000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Package Quantity | 250 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ripple Current | 2.56A |
| RoHS Compliant | Yes |
| Series | GU |
| Termination | Snap in |
| Test Frequency | 120Hz |
| Tolerance | 20% |
| Voltage Rating | 50V |
| DC Rated Voltage | 50V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon LGU1H472MELZ Datasheet
Download the complete datasheet for Nichicon LGU1H472MELZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
