High-performance aluminum electrolytic capacitor with 100µF capacitance and 450V DC rated voltage. Features a 20% tolerance, 690mA ripple current capability, and a rated life of 3000 hours at 105°C. This through-hole mount component has a 20mm diameter, 45mm height, and 10mm lead pitch with snap-in termination. Operating temperature range is -25°C to 105°C.
PackageRadial
Voltage450V
Capacitance100uF
Voltage Rating450V
Quick Jump:
Chat with Datasheet
Sponsored by
Sign in to ask questions about the Nichicon LGU2W101MELY datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Technical Specifications
Nichicon LGU2W101MELY technical specifications.
General
| Capacitance | 100uF |
| Package/Case | Radial |
| Diameter | 20mm |
| Height | 45mm |
| Lead Diameter | 0.8mm |
| Lead Free | Lead Free |
| Lead Pitch | 10mm |
| Leakage Current | 630uA |
| Length | 45mm |
| Life (Hours) | 3000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -25°C |
| Mount | Through Hole, PCB |
| Package Quantity | 250 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ripple Current | 690mA |
| RoHS Compliant | Yes |
| Series | GU |
| Termination | Snap in |
| Tolerance | 20% |
| Voltage | 450V |
| Voltage Rating | 450V |
| DC Rated Voltage | 450V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon LGU2W101MELY Datasheet
Download the complete datasheet for Nichicon LGU2W101MELY to view detailed technical specifications.
The embedded preview will load automatically when this section scrolls into view.
Product Images
