Nichicon's LLS2D821MELB is a 820uF 200V through hole aluminum electrolytic capacitor with a maximum operating temperature of 85°C and a minimum operating temperature of 3000°C. It has a leakage current of 1.21mA and a ripple current of 2.8A. The capacitor is lead free and RoHS compliant, packaged in bulk with 200 units per package. It is designed for general purpose applications and has a life of 3000 hours.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Nichicon LLS2D821MELB datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Capacitance | 820uF |
| Diameter | 30mm |
| Features | General Purpose |
| Height | 30mm |
| Height - Seated (Max) | 1.181inch |
| Lead Free | Lead Free |
| Lead Pitch | 10mm |
| Leakage Current | 1.21mA |
| Length | 30mm |
| Life (Hours) | 3000Hour |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | 3000°C |
| Mount | Through Hole, PCB |
| Package Quantity | 200 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ripple Current | 2.8A |
| RoHS Compliant | Yes |
| Series | LS |
| Termination | Snap in |
| Tolerance | 20% |
| Voltage Rating | 200V |
| DC Rated Voltage | 200V |
| RoHS | Compliant |
