680µF, 6.3V aluminum electrolytic capacitor with 20% tolerance. Features a 600mA ripple current rating and 5000-hour life at 105°C. Surface mountable in an 8x10mm cylindrical radial package, this AEC-Q200 qualified component offers 160mΩ impedance and 42.84µA leakage current. Designed for automotive applications, it operates from -55°C to 105°C and is supplied in tape and reel packaging.
PackageRadial
Voltage6.3V
Capacitance680uF
Voltage Rating6.3V
Quick Jump:
Technical Specifications
Nichicon UCD0J681MNL1GS technical specifications.
General
| Capacitance | 680uF |
| Package/Case | Radial |
| Construction | Cylindrical |
| Diameter | 8mm |
| Dissipation Factor | 0.26% |
| Height | 10mm |
| Height - Seated (Max) | 0.413inch |
| Impedance | 160mR |
| Leakage Current | 42.84uA |
| Length | 10mm |
| Life (Hours) | 5000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount, PCB |
| Package Quantity | 500 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Ratings | AEC-Q200 |
| Ripple Current | 600mA |
| RoHS Compliant | Yes |
| Series | CD |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage | 6.3V |
| Voltage Rating | 6.3V |
| DC Rated Voltage | 6.3V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon UCD0J681MNL1GS Datasheet
Download the complete datasheet for Nichicon UCD0J681MNL1GS to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
