Aluminum electrolytic capacitor with 330µF capacitance and 10V DC rated voltage, offering 20% tolerance. Features a radial package with 3.5mm lead pitch, 8mm diameter, and 11.5mm height. Operates across a -55°C to 105°C temperature range, with a ripple current of 350mA and 3000-hour life expectancy. Includes a leakage current of 99µA and an impedance of 160mR.
PackageRadial
Voltage10V
Capacitance330uF
Voltage Rating10V
Quick Jump:
Technical Specifications
Nichicon UPM1A331MPD technical specifications.
General
Capacitance
330uF
Package/Case
Radial
Construction
RADIAL
Diameter
8mm
Dielectric Material
Aluminium
Dissipation Factor
0.19%
Height
11.5mm
Height - Seated (Max)
0.512inch
Impedance
160mR
Lead Diameter
0.6mm
Lead Pitch
3.5mm
Leakage Current
99uA
Length
11.5mm
Life (Hours)
3000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole, PCB
Package Quantity
200
Packaging
Bulk
Radiation Hardening
No
Ripple Current
350mA
RoHS Compliant
Yes
Series
PM
Termination
Radial
Tolerance
20%
Voltage
10V
Voltage Rating
10V
DC Rated Voltage
10V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPM1A331MPD Datasheet
Download the complete datasheet for Nichicon UPM1A331MPD to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
