PackageRadial
Capacitance680uF
Voltage Rating10V
MountingThrough Hole
Quick Jump:
Technical Specifications
Nichicon UPS1A681MPD technical specifications.
General
Capacitance
680uF
Package/Case
Radial
Diameter
10mm
Height
12.5mm
Impedance
190mR
Lead Pitch
5mm
Leakage Current
204uA
Length
12.5mm
Life (Hours)
2000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole
Package Quantity
200
Packaging
Bulk
Radiation Hardening
No
Ripple Current
600mA
RoHS Compliant
Yes
Series
UPS
Termination
Radial
Tolerance
20%
Voltage Rating
10V
DC Rated Voltage
10V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPS1A681MPD Datasheet
Download the complete datasheet for Nichicon UPS1A681MPD to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
