PackageRadial
Capacitance1uF
Voltage Rating200V
MountingThrough Hole
Quick Jump:
Technical Specifications
Nichicon UPS2D010MED technical specifications.
General
Capacitance
1uF
Package/Case
Radial
Diameter
6.3mm
Height
11mm
Height - Seated (Max)
0.492inch
Lead Pitch
2.5mm
Leakage Current
60uA
Length
11mm
Life (Hours)
2000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Mount
Through Hole
Package Quantity
200
Packaging
Bulk
Radiation Hardening
No
Ripple Current
17mA
RoHS Compliant
Yes
Series
PS
Termination
Radial
Tolerance
20%
Voltage Rating
200V
DC Rated Voltage
200V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPS2D010MED Datasheet
Download the complete datasheet for Nichicon UPS2D010MED to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
