PackageRadial
Capacitance47uF
Voltage Rating200V
MountingThrough Hole
Quick Jump:
Technical Specifications
Nichicon UPS2D470MHD technical specifications.
General
Capacitance
47uF
Package/Case
Radial
Diameter
12.5mm
Height
25mm
Height - Seated (Max)
1.063inch
Lead Pitch
5mm
Leakage Current
476uA
Length
25mm
Life (Hours)
3000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Mount
Through Hole
Package Quantity
100
Packaging
Bulk
Radiation Hardening
No
Ripple Current
220mA
RoHS Compliant
Yes
Series
PS
Termination
Radial
Tolerance
20%
Voltage Rating
200V
DC Rated Voltage
200V
Compliance
RoHS
Compliant
Datasheet
Nichicon UPS2D470MHD Datasheet
Download the complete datasheet for Nichicon UPS2D470MHD to view detailed technical specifications.
