Aluminum electrolytic capacitor, 47µF capacitance, 400V voltage rating, and 20% tolerance. Features a 7.5mm lead pitch and 18mm diameter, with a seated height of 35.5mm. Offers a ripple current of 170mA and a life expectancy of 3000 hours at 105°C. Operating temperature range is -40°C to 105°C.
PackageRadial
Capacitance47uF
Voltage Rating400V
MountingThrough Hole
Quick Jump:
Chat with Datasheet
Sponsored by
Sign in to ask questions about the Nichicon UPS2G470MHD datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Technical Specifications
Nichicon UPS2G470MHD technical specifications.
General
| Capacitance | 47uF |
| Package/Case | Radial |
| Diameter | 18mm |
| Dielectric Material | Aluminium |
| Features | General Purpose |
| Height | 35.5mm |
| Height - Seated (Max) | 1.476inch |
| Lead Pitch | 7.5mm |
| Leakage Current | 852uA |
| Length | 35.5mm |
| Life (Hours) | 3000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Package Quantity | 50 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ripple Current | 170mA |
| RoHS Compliant | Yes |
| Series | PS |
| Termination | Radial |
| Tolerance | 20% |
| Voltage Rating | 400V |
| DC Rated Voltage | 400V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon UPS2G470MHD Datasheet
Download the complete datasheet for Nichicon UPS2G470MHD to view detailed technical specifications.
The embedded preview will load automatically when this section scrolls into view.
Product Images
