Aluminum electrolytic capacitor with 22µF capacitance and 35V voltage rating. Features a 20% tolerance, 105°C maximum operating temperature, and 1000-hour life. Radial package measures 5mm in diameter and 11mm in height, with a 2mm lead pitch. Includes 61mA ripple current capability and 23.1µA leakage current. Through-hole, PCB mountable and RoHS compliant.
PackageRadial
Voltage35V
Capacitance22uF
Voltage Rating35V
Quick Jump:
Technical Specifications
Nichicon UVZ1V220MDD technical specifications.
General
Capacitance
22uF
Package/Case
Radial
Construction
RADIAL
Diameter
5mm
Dielectric Material
Aluminium
Dissipation Factor
0.14%
Height
11mm
Lead Diameter
0.5mm
Lead Free
Lead Free
Lead Pitch
2mm
Leakage Current
23.1uA
Length
11mm
Life (Hours)
1000Hour
Max Operating Temperature
105°C
Min Operating Temperature
-55°C
Mount
Through Hole, PCB
Package Quantity
200
Packaging
Bulk
Radiation Hardening
No
Reach SVHC Compliant
No
Ripple Current
61mA
RoHS Compliant
Yes
Series
VZ
Termination
Radial
Tolerance
20%
Voltage
35V
Voltage Rating
35V
DC Rated Voltage
35V
Compliance
RoHS
Compliant
Datasheet
Nichicon UVZ1V220MDD Datasheet
Download the complete datasheet for Nichicon UVZ1V220MDD to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
