Standard aluminum electrolytic capacitor with 470nF capacitance and 250V DC rated voltage. Features a 20% tolerance, 10mA ripple current, and 51.75uA leakage current. Radial package with 2.5mm lead pitch, 6.3mm diameter, and 11mm height. Operates from -40°C to 105°C with a 1000-hour life rating. Through-hole mounting for PCB applications.
PackageRadial
Voltage250V
Capacitance470nF
Voltage Rating250V
Quick Jump:
Technical Specifications
Nichicon UVZ2ER47MED technical specifications.
General
| Capacitance | 470nF |
| Package/Case | Radial |
| Construction | RADIAL |
| Diameter | 6.3mm |
| Dielectric Material | Aluminium |
| Dissipation Factor | 0.2% |
| Height | 11mm |
| Lead Diameter | 0.5mm |
| Lead Free | Lead Free |
| Lead Pitch | 2.5mm |
| Leakage Current | 51.75uA |
| Length | 11mm |
| Life (Hours) | 1000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole, PCB |
| Package Quantity | 100 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Ripple Current | 10mA |
| RoHS Compliant | Yes |
| Series | VZ |
| Termination | Radial |
| Tolerance | 20% |
| Voltage | 250V |
| Voltage Rating | 250V |
| DC Rated Voltage | 250V |
Compliance
| RoHS | Compliant |
Datasheet
Nichicon UVZ2ER47MED Datasheet
Download the complete datasheet for Nichicon UVZ2ER47MED to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
