This 28V SPDT rocker switch features a right-angle orientation and is designed for through-hole mounting. The switch has an illuminated actuator and a gold-plated contact. It is rated for 50,000 mechanical cycles and 50,000 electrical cycles. The switch is compliant with RoHS regulations but does not meet Reach SVHC requirements. It is available in a single unit package with a PC pin termination.
Checking distributor stock and pricing after the page loads.
| Actuator Type | Rocker |
| Color | Red |
| Contact Plating | Gold |
| Electrical Life | 50000Cycles |
| Illumination Type | Illuminated |
| Lead Free | Contains Lead |
| Max Operating Temperature | 85°C |
| Mechanical Life | 50000Cycles |
| Min Operating Temperature | -30°C |
| Mount | Through Hole |
| Orientation | Right Angle |
| Package Quantity | 1 |
| Packaging | Tray |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | GW |
| Switch Function | On-On |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 28V |
| DC Rated Voltage | 28V |
| RoHS | Compliant |
