Illuminated pushbutton switch featuring SPDT momentary contact, a round brass plunger actuator, and solder lug termination. Rated for 6A at 250VAC and 30VDC, with a silver contact material and plating. Offers a mechanical life of 100,000 cycles and an electrical life of 25,000 cycles. Panel mountable with a vertical orientation, operating within a temperature range of -30°C to 85°C. RoHS compliant and UL94 V-0 flammability rated.
Current Rating6A
MountingPanel
Quick Jump:
Technical Specifications
NKK Switches MB2011SS1W01-CA technical specifications.
General
Actuator Material
Brass
Actuator Type
Round, Button
Contact Current Rating
6A
Contact Material
Silver
Contact Plating
Silver
Current Rating
6A
Depth
10mm
Electrical Life
25000Cycles
Flammability Rating
UL94 V-0
Lead Free
Lead Free
Length
13mm
Max Current Rating
6A
Max Operating Temperature
85°C
Min Operating Temperature
-30°C
Max Voltage Rating (AC)
250V
Max Voltage Rating (DC)
30V
Mechanical Life
100000Cycles
Mount
Panel
Orientation
Vertical
Packaging
Bulk
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
MB2000
Switch Function
On-Mom
Termination
Solder
Throw Configuration
SPDT
Voltage Rating (AC)
125V
DC Rated Voltage
30V
Compliance
RoHS
Compliant
Datasheet
NKK Switches MB2011SS1W01-CA Datasheet
Download the complete datasheet for NKK Switches MB2011SS1W01-CA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
