Illuminated rotary switch featuring a 13mm brass knob actuator and 6 positions. This electromechanical component offers 2 poles per deck across 1 deck, with adjustable index stops at a 30° angle. Contact materials include bronze, brass, and silver with gold plating, providing non-shorting functionality. Rated for 250mA at 28V AC/DC, it supports through-hole and panel mounting with PC pin termination.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NKK Switches MRK206-A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Length | 13mm |
| Actuator Material | Brass |
| Actuator Type | KNOB TYPE |
| Contact Material | Bronze, Brass, Silver |
| Contact Plating | Gold |
| Contact Style | Non-Shorting |
| Contact Type | 2 makers |
| Current Rating | 250mA |
| Depth | 12.6mm |
| Illumination Type | Illuminated |
| Index Angle | 30° |
| Index Stops | Adjustable |
| Lead Free | Lead Free |
| Length | 12.6mm |
| Material | Metal |
| Max Current Rating | 100mA |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -10°C |
| Max Voltage Rating (AC) | 28V |
| Max Voltage Rating (DC) | 28V |
| Mount | Through Hole, Panel |
| Number of Decks | 1 |
| Number of Poles | 2 |
| Number of Poles per Deck | 2 |
| Number of Positions | 6 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | MR |
| Termination | PC Pin |
| Throw Configuration | DP6T, DP5T, DP |
| Voltage Rating (AC) | 28V |
| DC Rated Voltage | 28V |
| RoHS | Compliant |
