Illuminated pushbutton switch with SPST, normally open configuration. Features silver-plated copper contacts rated for 2A continuous current and 3A maximum. Offers a mechanical life of 30,000 cycles and an electrical life of 10,000 cycles. Panel-mount design with solder termination, operating temperature range of -10°C to 70°C, and AC voltage rating of 125V (250V max) and DC voltage rating of 30V. Actuator is a round, black phenolic resin button.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NKK Switches SB4011NOH-2A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Actuator Material | Resin, Phenolic |
| Actuator Type | Round, Button |
| Contact Current Rating | 3A |
| Contact Material | Silver, Copper |
| Contact Plating | Silver |
| Current Rating | 2A |
| Depth | 12mm |
| Electrical Life | 10000Cycles |
| Lead Free | Lead Free |
| Length | 12mm |
| Max Current Rating | 3A |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -10°C |
| Max Voltage Rating (AC) | 250V |
| Max Voltage Rating (DC) | 30V |
| Mechanical Life | 30000Cycles |
| Mount | Panel |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Orientation | Vertical |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | SB40 |
| Switch Function | Off-Mom |
| Termination | Solder |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 125V |
| DC Rated Voltage | 30V |
| RoHS | Compliant |
