The MIFARE RFID reader module operates at 13.56MHz with a data rate of 10Mbps, supporting I2C, SPI, and UART interfaces. It is designed for surface mount applications and is compliant with RoHS regulations. The module has a maximum operating temperature of 85°C and a minimum operating temperature of -30°C, with a supply voltage range of 2.5V to 3.6V. It is available in a QFN package quantity of 490, packaged in a tray.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the NXP PN5120A0HN/C1,551 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Module |
| Data Rate | 10Mbps |
| Frequency | 13.56MHz |
| Interface | I2C, SPI, UART |
| Lead Free | Lead Free |
| Max Dual Supply Voltage | 3.6V |
| Max Frequency | 13.56MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -30°C |
| Max Supply Voltage | 3.6V |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Number of Receivers | 1 |
| Number of Transmitters | 1 |
| Package Quantity | 490 |
| Packaging | Tray |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | MIFARE® |
| RoHS | Compliant |
Download the complete datasheet for NXP PN5120A0HN/C1,551 to view detailed technical specifications.
