Omron
B3F-6052BYOMZ
Switch Tactile N.O. SPST Projected Plunger PC Pins 0.05A 24VDC 1.47N Thru-Hole Tape
MountingThrough Hole
Quick Jump:
Technical Specifications
Omron B3F-6052BYOMZ technical specifications.
General
| Illumination Type | Non-Illuminated |
| Max Operating Temperature | 70°C |
| Mechanical Life | 300000Cycles |
| Min Operating Temperature | -25°C |
| Mount | Through Hole |
| Operating Force | 150gf |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Series | B3F |
| Switch Function | Off-Mom |
| Switch Travel | 0.25mm |
| Termination | PC Pin |
| Throw Configuration | SPST |
Compliance
| RoHS | Compliant |
Datasheet
Omron B3F-6052BYOMZ Datasheet
Download the complete datasheet for Omron B3F-6052BYOMZ to view detailed technical specifications.
No datasheet is available for this part.
Product Images
