Technical Specifications
Omron G2R-1-AC120 technical specifications.
General
Coil Current
7.5mA
Coil Resistance
6.5kR
Coil Type
Non-Latching
Coil Voltage (AC)
120V
Contact Current Rating
10A
Contact Material
Silver
Lead Free
Lead Free
Max Current Rating
10A
Max Operating Temperature
70°C
Min Operating Temperature
-40°C
Max Voltage Rating (AC)
380V
Max Voltage Rating (DC)
125V
Mount
Through Hole
Operate Time
15ms
Packaging
Tray
Power Consumption
900mW
Relay Type
General Purpose
Release Time
10ms
RoHS Compliant
Yes
Series
G2R
Termination
PC Pin
Throw Configuration
SPDT
Weight
17g
Compliance
RoHS
Compliant
Datasheet
Omron G2R-1-AC120 Datasheet
Download the complete datasheet for Omron G2R-1-AC120 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
