The Omron G6DS-1A-H24VDC is a 1-form-C PCB mount switch with a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. It has a durability of 106 cycles and is rated for an IP67 rating. The switch has a switching current of 5A and is RoHS compliant. It measures 12.5mm in height, 21.3mm in length, and 5.08mm in width, with a package case size of 120.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron G6DS-1A-H24VDC datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | 120 |
| Contact Type | 1 maker |
| Durability | 106Cycles |
| Height | 12.5mm |
| Length | 21.3mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | PCB |
| Ratings | IP67 |
| RoHS Compliant | Yes |
| Switching Current | 5A |
| Width | 5.08mm |
| RoHS | Compliant |
Download the complete datasheet for Omron G6DS-1A-H24VDC to view detailed technical specifications.
