DPDT General Purpose Power Relay with a 10A contact current rating at 250VAC/250VDC. Features a 120VAC non-latching coil with 18mA coil current and 1.578kR coil resistance. Offers 20ms operate and release times, silver contact material, and socketable plug termination. Operates within a -10°C to 40°C temperature range.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Omron MK2PNSAC120 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Coil Current | 18mA |
| Coil Resistance | 1.578kR |
| Coil Type | Non-Latching |
| Coil Voltage (AC) | 120V |
| Contact Current Rating | 10A |
| Contact Material | Silver |
| Current Rating | 10A |
| Depth | 34.5mm |
| Height | 52.5mm |
| Lead Free | Lead Free |
| Length | 34.5mm |
| Max Operating Temperature | 40°C |
| Min Operating Temperature | -10°C |
| Mount | Socketable |
| Mounting Style | SOCKET |
| Operate Time | 20ms |
| Package Quantity | 1 |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Release Time | 20ms |
| Series | MK |
| Termination | Plug |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 250V |
| DC Rated Voltage | 250V |
| Width | 34.5mm |
| RoHS | Compliant |
