SFT1341-TL-E

Name: SFT1341-TL-E Onsemi
Brand: Onsemi
SKU: SFT1341-TL-E

MOSFET P-CH

PackageDPAK

PolarityP-CHANNEL

Power15W

Quick Jump:

Onsemi SFT1341-TL-E technical specifications.

Package/Case	DPAK
Continuous Drain Current (ID)	10A
Drain to Source Breakdown Voltage	40V
Drain to Source Resistance	112mR
Drain to Source Voltage (Vdss)	40V
Element Configuration	Single
Fall Time	80ns
Gate to Source Voltage (Vgs)	10V
Input Capacitance	650pF
Lead Free	Lead Free
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Max Power Dissipation	15W
Packaging	Tape and Reel
Polarity	P-CHANNEL
Power Dissipation	15W
Radiation Hardening	No
Rds On Max	112mR
Turn-Off Delay Time	81ns
Turn-On Delay Time	9ns
