The Opto 22 OAC5A is a 3A SPST relay module with 4kV isolation voltage and a DC rated voltage of 5V. It has a maximum operating temperature of 70°C and a minimum operating temperature of -30°C. The module is approved by UL and is available in a module package type. It is designed for rack, through hole, or plug-in mounting and has a width of 15.2mm, a length of 43.2mm, a height of 31.8mm, and a depth of 31.8mm.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Opto 22 OAC5A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Opto 22 OAC5A technical specifications.
| Approvals | UL |
| Package/Case | Module |
| Current Rating | 3A |
| Depth | 31.8mm |
| Height | 31.8mm |
| Isolation Voltage | 4kV |
| Length | 43.2mm |
| Load Current | 3A |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -30°C |
| Mount | Rack, Through Hole, Plug-In |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Output Current | 3A |
| Output Type | Analog |
| Reach SVHC Compliant | No |
| Termination | PC Pins |
| Throw Configuration | SPST |
| DC Rated Voltage | 5V |
| Width | 15.2mm |
| RoHS | Compliant |
