The ACJ1212P is a 12V non-latching relay coil with a maximum current rating of 53.3mA and a power consumption of 640mW. It has a coil resistance of 225 ohms and is designed for through-hole PCB mounting. The relay operates within a temperature range of -40°C to 85°C and is compliant with RoHS regulations. The ACJ1212P is available in a package quantity of 70 and is supplied in a rail/tube packaging format.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic ACJ1212P datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic ACJ1212P technical specifications.
| Coil Current | 53.3mA |
| Coil Power | 640mW |
| Coil Resistance | 225R |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12V |
| Contact Current Rating | 20A |
| Contact Material | Silver, Cadmium |
| Depth | 7.2mm |
| Height | 13.8mm |
| Length | 12.2mm |
| Life (Hours) | 10000000Hour |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (DC) | 14V |
| Mount | Through Hole, PCB |
| Operate Time | 10ms |
| Package Quantity | 70 |
| Packaging | Rail/Tube |
| Release Time | 10ms |
| RoHS Compliant | Yes |
| Series | ACJ |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| RoHS | Compliant |
