The AQN611VL is a solid state relay from Panasonic with a maximum operating temperature of 80°C and a minimum operating temperature of -20°C. It has a maximum input current of 20mA and a maximum output current of 40A. The relay is RoHS compliant and features a screw termination. It is available in bulk packaging with 2 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic AQN611VL datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic AQN611VL technical specifications.
| Contact Type | 1 Closer |
| Input Type | DC |
| Max Input Current | 20mA |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -20°C |
| Max Output Current | 40A |
| Max Output Voltage | 250V |
| Mount | Screw |
| Package Quantity | 2 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Termination | Screw |
| Throw Configuration | SPST |
| RoHS | Compliant |
