General purpose electromechanical relay featuring a 2 Form A (DPST) contact configuration. Coil operates at 24VDC with 200mW power consumption and 8.3mA current. Contacts rated for 8A switching current and 30VDC, with Tin/Silver material. Through-hole mounting with straight PC pin termination. Operate and release times are 10ms and 5ms respectively.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic DE2A-24V datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic DE2A-24V technical specifications.
| Package/Case | DIP |
| Coil Current | 8.3mA |
| Coil Resistance | 2.88kR |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 24V |
| Contact Current Rating | 8A |
| Contact Material | Tin, Silver |
| Current Rating | 8A |
| Height | 12.8mm |
| Lead Free | Lead Free |
| Max Current Rating | 8A |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 440V |
| Max Voltage Rating (DC) | 230V |
| Mount | Through Hole |
| Number of Contacts | 2 |
| Operate Time | 10ms |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Power Consumption | 200mW |
| Reach SVHC Compliant | Unknown |
| Relay Type | General Purpose |
| Release Time | 5ms |
| RoHS Compliant | Yes |
| Series | DE |
| Switching Current | 8A |
| Termination | PC Pin |
| Throw Configuration | DPST |
| Weight | 7g |
| RoHS | Compliant |
