Radial aluminum electrolytic capacitor with 100µF capacitance and 20% tolerance. Features a 50V DC rated voltage, 250mA ripple current, and 3mA leakage current. Designed for through-hole PCB mounting with a 5mm lead pitch and 8mm diameter. Operating temperature range from -40°C to 85°C with a 2000-hour life rating.
PackageRadial
Voltage50V
Capacitance100uF
Voltage Rating50V
Quick Jump:
Technical Specifications
Panasonic ECA-1HM101B technical specifications.
General
Capacitance
100uF
Package/Case
Radial
Construction
RADIAL
Diameter
8mm
Dissipation Factor
0.12%
Height
11.5mm
Lead Diameter
0.6mm
Lead Free
Lead Free
Lead Pitch
5mm
Lead/Base Style
Straight
Leakage Current
3mA
Length
11.5mm
Life (Hours)
2000Hour
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Through Hole, PCB
Package Quantity
1000
Packaging
Ammo Pack
Radiation Hardening
No
Reach SVHC Compliant
Unknown
Ripple Current
250mA
RoHS Compliant
Yes
Series
M
Termination
Radial
Tolerance
20%
Voltage
50V
Voltage Rating
50V
DC Rated Voltage
50V
Width
8mm
Compliance
RoHS
Compliant
Datasheet
Panasonic ECA-1HM101B Datasheet
Download the complete datasheet for Panasonic ECA-1HM101B to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
