Surface mount aluminum electrolytic capacitor with 220µF capacitance and 6.3V DC rated voltage. Features a 5x5.8mm cylindrical radial package, 360mΩ ESR, and 240mA ripple current. Operates from -55°C to 105°C with a 2000-hour life expectancy. Compliant with RoHS and AEC-Q200 standards.
PackageRadial
Voltage6.3V
Capacitance220uF
Voltage Rating6.3V
Quick Jump:
Technical Specifications
Panasonic EEE-FT0J221AR technical specifications.
General
| Capacitance | 220uF |
| Package/Case | Radial |
| Construction | Cylindrical |
| Diameter | 5mm |
| Dissipation Factor | 26% |
| ESR (Equivalent Series Resistance) | 360mR |
| Height | 5.8mm |
| Lead Diameter | 0.65mm |
| Lead Pitch | 1.5mm |
| Leakage Current | 13.8uA |
| Length | 5.8mm |
| Life (Hours) | 2000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Package Quantity | 1000 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Ratings | AEC-Q200 |
| Reach SVHC Compliant | No |
| Ripple Current | 240mA |
| Ripple Current (AC) | 240mA |
| RoHS Compliant | Yes |
| Series | FT |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage | 6.3V |
| Voltage Rating | 6.3V |
| DC Rated Voltage | 6.3V |
Compliance
| RoHS | Compliant |
Datasheet
Panasonic EEE-FT0J221AR Datasheet
Download the complete datasheet for Panasonic EEE-FT0J221AR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
