330µF, 2V polymer aluminum electrolytic capacitor with 4.5mΩ ESR and 3.8A ripple current. Features a 7.3mm x 7.3mm x 4.3mm SMD/SMT construction, operating from -40°C to 105°C with a 1000-hour life rating. This RoHS compliant component offers 20% capacitance tolerance and a leakage current of 66µA.
Sign in to ask questions about the Panasonic EEF-LX0D331R4 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic EEF-LX0D331R4 technical specifications.
| Capacitance | 330uF |
| Case Code (Imperial) | 2917 |
| Case Code (Metric) | 7343 |
| Construction | Flat |
| Depth | 4.3mm |
| Dielectric Material | Aluminium |
| ESR (Equivalent Series Resistance) | 4.5mR |
| Height | 1.9mm |
| Lead Diameter | 2.4mm |
| Leakage Current | 66uA |
| Length | 7.3mm |
| Life (Hours) | 1000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Packaging | Cut Tape |
| Reach SVHC Compliant | Unknown |
| Ripple Current | 3.8A |
| Ripple Current (AC) | 3.8A |
| RoHS Compliant | Yes |
| Series | LX |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage | 2V |
| Voltage Rating | 2V |
| Width | 7.3mm |
| RoHS | Compliant |
