This Panasonic general purpose aluminum electrolytic capacitor has a capacitance of 330uF, a voltage rating of 50V, and a dissipation factor of 10%. It is available in a radial package with a diameter of 12.5mm and a height of 14.3mm. The capacitor has a maximum operating temperature of 105°C and a minimum operating temperature of -55°C. It is suitable for surface mount applications and is packaged on a tape and reel with 200 units per reel.
Sign in to ask questions about the Panasonic EEV-FK1H331V datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic EEV-FK1H331V technical specifications.
| Capacitance | 330uF |
| Package/Case | Radial |
| Diameter | 12.5mm |
| Dissipation Factor | 10% |
| ESR (Equivalent Series Resistance) | 120mR |
| Features | General Purpose |
| Height | 14.3mm |
| Height - Seated (Max) | 0.551inch |
| Leakage Current | 165uA |
| Life (Hours) | 5000Hour |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Package Quantity | 200 |
| Packaging | Tape and Reel |
| Ripple Current | 900mA |
| Series | FK |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage Rating | 50V |
| DC Rated Voltage | 50V |
| RoHS | Compliant |
