Surface mount PTC resettable fuse with a 750mA current rating and 32V DC voltage rating. Features a 0603 (1608 metric) alumina case, measuring 1.6mm x 0.8mm x 0.54mm. Offers a DC cold resistance of 190mR and operates within a temperature range of -40°C to 125°C. UL approved and RoHS compliant, supplied in tape and reel packaging.
Package0603
Current750mA
Voltage Rating32V
Current Rating750mA
Quick Jump:
Technical Specifications
Panasonic ERB-RE0R75V technical specifications.
General
Approvals
UL
Body Material
Alumina
Case Code (Imperial)
0603
Case Code (Metric)
1608
Package/Case
0603
Current
750mA
Current Rating
750mA
DC Cold Resistance
190mR
Depth
0.8mm
Fuse Current
750mA
Fuse Size
1.6 X 0.8mm
Height
0.54mm
Length
1.6mm
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Voltage Rating (DC)
32V
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
ERB-RE
Voltage Rating
32V
DC Rated Voltage
32V
Width
0.8mm
Compliance
RoHS
Compliant
Datasheet
Panasonic ERB-RE0R75V Datasheet
Download the complete datasheet for Panasonic ERB-RE0R75V to view detailed technical specifications.
