Surface mount resettable fuse, 2A current rating, 32V DC maximum voltage. Features 51mR DC cold resistance and a compact 0603 (1608) case size. Operates across a wide temperature range from -40°C to 125°C. Constructed with an alumina body and supplied on tape and reel. RoHS compliant and UL approved.
Sign in to ask questions about the Panasonic ERB-RE2R00V datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic ERB-RE2R00V technical specifications.
| Approvals | UL |
| Body Material | Alumina |
| Case Code (Imperial) | 0603 |
| Case Code (Metric) | 1608 |
| Package/Case | 0603 |
| Current | 2A |
| Current Rating | 2A |
| DC Cold Resistance | 51mR |
| Depth | 0.8mm |
| Fuse Current | 2A |
| Fuse Size | 1.6 X 0.8mm |
| Height | 0.54mm |
| Lead Free | Lead Free |
| Length | 1.6mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (DC) | 32V |
| Mount | Surface Mount |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | ERB-RE |
| Voltage Rating | 32V |
| DC Rated Voltage | 32V |
| Width | 0.8mm |
| RoHS | Compliant |
