Radial, through-hole SIDAC with 18V varistor voltage and 10% tolerance. Features 11V AC max voltage rating, 14V DC rated voltage, and 20V max varistor voltage. Offers 250A max surge current, 1A clamping current, and 40V clamping voltage. Operates from -40°C to 85°C with 1.6nF capacitance and 0.6J energy rating. Packaged in bulk with 1000 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic ERZ-V05D180 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic ERZ-V05D180 technical specifications.
| Capacitance | 1.6nF |
| Package/Case | Metal |
| Clamping Current | 1A |
| Clamping Voltage | 40V |
| Depth | 4.5mm |
| Diameter | 5mm |
| Energy | 0.6J |
| ESD Protection | No |
| Height | 10mm |
| Lead Free | Lead Free |
| Lead Pitch | 5mm |
| Lead/Base Style | Radial |
| Material | Zinc |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 11V |
| Max Surge Current | 250A |
| Max Varistor Voltage | 20V |
| Min Varistor Voltage | 16V |
| Max Voltage Rating (AC) | 11V |
| Max Voltage Rating (DC) | 14V |
| Mount | Radial, Through Hole |
| Number of Circuits | 1 |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Series | V |
| Termination | Radial |
| Thickness | 4.5mm |
| Varistor Voltage | 18V |
| Voltage Rating (AC) | 11V |
| DC Rated Voltage | 14V |
| Voltage Tolerance | 10% |
| Width | 4.5mm |
| RoHS | Compliant |
