Radial, through-hole SIDAC with a 39V varistor voltage, 10% tolerance, and 1kA max surge current. Features 77V clamping voltage, 5A clamping current, and 5.6J energy rating. Operates within a -40°C to 85°C temperature range, with 25V AC and 31V DC rated voltages. Constructed with a zinc metal package, it offers a 7.5mm lead pitch and a 11.5mm diameter.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic ERZ-V10D390 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic ERZ-V10D390 technical specifications.
| Capacitance | 5.2nF |
| Package/Case | Metal |
| Clamping Current | 5A |
| Clamping Voltage | 77V |
| Depth | 4.9mm |
| Diameter | 11.5mm |
| Energy | 5.6J |
| Lead Free | Lead Free |
| Lead Pitch | 7.5mm |
| Lead/Base Style | Radial |
| Material | Zinc |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 25V |
| Max Surge Current | 1kA |
| Max Varistor Voltage | 43V |
| Min Varistor Voltage | 35V |
| Max Voltage Rating (AC) | 25V |
| Max Voltage Rating (DC) | 31V |
| Mount | Radial, Through Hole |
| Number of Circuits | 1 |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | V |
| Termination | Radial |
| Thickness | 4.9mm |
| Varistor Voltage | 39V |
| Voltage | 39V |
| Voltage Rating (AC) | 25V |
| DC Rated Voltage | 31V |
| Voltage Tolerance | 10% |
| Width | 7.5mm |
| RoHS | Compliant |
