Radial SIDAC with 470V varistor voltage and 10% tolerance. Features 6kA max surge current, 50A clamping current, and 775V clamping voltage. Operates within -40°C to 85°C, with a 300V AC maximum voltage rating and 385V DC rated voltage. Includes 400pF capacitance and 175J energy rating in a 14mm disc package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic ERZ-V14D471 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Panasonic ERZ-V14D471 technical specifications.
| Capacitance | 400pF |
| Package/Case | Metal |
| Clamping Current | 50A |
| Clamping Voltage | 775V |
| Clamping Voltage-Max | 775V |
| Depth | 6.2mm |
| Diameter | 15.5mm |
| Energy | 175J |
| ESD Protection | No |
| Height | 18.5mm |
| Lead Free | Lead Free |
| Lead Pitch | 7.5mm |
| Lead/Base Style | Radial |
| Material | Zinc |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 300V |
| Max Surge Current | 6kA |
| Max Varistor Voltage | 517V |
| Min Varistor Voltage | 423V |
| Max Voltage Rating (AC) | 300V |
| Max Voltage Rating (DC) | 385V |
| Mount | Radial, Through Hole |
| Number of Circuits | 1 |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | V |
| Termination | Radial |
| Thickness | 6.2mm |
| Varistor Voltage | 470V |
| Voltage | 470V |
| Voltage Rating | 300V |
| Voltage Rating (AC) | 300V |
| DC Rated Voltage | 385V |
| Voltage Tolerance | 10% |
| Width | 7.5mm |
| RoHS | Compliant |
