The Panasonic VS5-24V is a dual coil latching relay with a maximum operating temperature of 80°C and a minimum operating temperature of -20°C. It has a maximum output current of 100mA and a maximum output voltage of 30V. The relay is powered by a 24V supply with a minimum supply voltage of 5V. It is designed for surface mount applications and is packaged in a SIP format.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Panasonic VS5-24V datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SIP |
| Coil Type | Latching, Dual Coil |
| Lead Free | Lead Free |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -20°C |
| Max Output Current | 100mA |
| Max Output Voltage | 30V |
| Max Supply Voltage | 24V |
| Min Supply Voltage | 5V |
| Mount | Surface Mount |
| Number of Outputs | 2 |
| Output Current | 100mA |
| Package Quantity | 100 |
| Power Consumption | 520mW |
| Reach SVHC Compliant | No |
| Series | VS |
| Termination | Through Hole |
| Throw Configuration | SPST |
| Weight | 0.7g |
| RoHS | Compliant |
