The AVX CWR29HB226KTGC\TR is a 22uF surface mount tantalum capacitor with a voltage rating of 15VDC and a tolerance of 10%. It features a low ESR of 0.275 and a leakage current of 4uA. The capacitor is constructed with a flat construction and has a termination style of inward L. It has a high reliability feature and operates over a temperature range of -55 to 125 degrees Celsius.
AVX CWR29HB226KTGC\TR technical specifications.
| Capacitance | 22uF |
| Voltage | 15VDC |
| Tolerance | 10% |
| ESR | 0.275Ohm |
| Leakage Current | 4uA |
| Case Code | G |
| Min Operating Temperature | -55°C |
| Max Operating Temperature | 125°C |
| Mounting | Surface Mount |
| Termination Style | Inward L |
| Construction | Flat |
| ESR Type | Low |
| Special Features | High Reliability |
| RoHS | Yes |
| RoHS Version | 2011/65/EU, 2015/863 |
No datasheet is available for this part.
