Phoenix Contact
2838228
Surge Arrestor Protective Plug With Protective Circuit 28VDC/20VAC 10KA DIN Rail
Current Rating450mA
MountingBase, DIN Rail, Socket
Quick Jump:
Technical Specifications
Phoenix Contact 2838228 technical specifications.
General
| Approvals | UL, GOST, EAC |
| Color | Black |
| Current Rating | 450mA |
| Depth | 17.7mm |
| Height | 65.5mm |
| Lead Free | Lead Free |
| Length | 90mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Base, DIN Rail, Socket |
| Number of Conductors | 8 |
| Package Quantity | 1 |
| Ratings | IP20 |
| Response Time | 1ns |
| Series | PT |
| Termination | Screw |
| DC Rated Voltage | 24V |
| Weight | 0.750983oz |
Compliance
| RoHS | Compliant |
Datasheet
Phoenix Contact 2838228 Datasheet
Download the complete datasheet for Phoenix Contact 2838228 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
