Ethernet Pulse Transformer for 10/100 BASE-TX applications. Features a 1:1 turns ratio and a compact module package with a maximum seated height of 5.97mm. Surface mountable with dimensions of 12.7mm length and 7.11mm width. Supplied in a package quantity of 600 units and is RoHS compliant.
PackageModule
MountingSurface Mount
Quick Jump:
Technical Specifications
Pulse HX2326NLT technical specifications.
General
| Package/Case | Module |
| Height - Seated (Max) | 5.97mm |
| Length | 12.7mm |
| Mount | Surface Mount |
| Package Quantity | 600 |
| RoHS Compliant | Yes |
| Width | 7.11mm |
Compliance
| RoHS | Compliant |
Datasheet
Pulse HX2326NLT Datasheet
Download the complete datasheet for Pulse HX2326NLT to view detailed technical specifications.
