The PE-51717NL is a 20A current rating, 5mH inductance inductor with a radial lead termination and a maximum operating temperature of 130°C. It is available in a bulk packaging with 60 units per package. The inductor has a minimum operating temperature of -40°C and is RoHS compliant. It has a DC resistance of 700mR and a lead pitch of 12.7mm.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Pulse PE-51717NL datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Current Rating | 20A |
| DC Current | 20A |
| DC Resistance (DCR) | 700mR |
| Depth | 9.91mm |
| Height | 20.32mm |
| Inductance | 5mH |
| Lead Pitch | 12.7mm |
| Lead/Base Style | Pin |
| Length | 17.01mm |
| Max DC Current | 20A |
| Max Operating Temperature | 130°C |
| Military Standard | Not |
| Min Operating Temperature | -40°C |
| Package Quantity | 60 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Termination | Radial |
| Test Frequency | 15.75kHz |
| Width | 9.906mm |
| RoHS | Compliant |
